Vitus Escarpe 29 Cr Mountain Bike
VITUS ESCARPE 29 CR: THE RIGHT BIKE FOR ANY JOB
For the big ups and the big downs, the all-day adventures and after work hot laps, the Vitus Escarpe 29 CR trail bike is the perfect tool for any job. Have room in your life for just one bike but want to ride ALL the trails? You’re looking at the right bike.
With a carbon T700 front triangle paired with an alloy rear triangle built on a Horst-link suspension platform, the Escarpe 29 CR balances pedaling efficiency with downhill capability. Special attention has been paid to eliminating pedal bob on the climbs, and short 440mm chainstays paired with a smartly designed suspension kinematic make the Escarpe 29 feel flickable and spry on descents.
Balance is the driving idea behind the Escarpe 29 — it’s a trail bike that harnesses balanced geometry and a primo component package to be capable just about anywhere you’d want to take it. The 29-inch wheel setup and 150mm/140mm suspension platform emphasizes traction and is smooth like butter on demanding trails. It’s a bike that’ll meet your limits and help push you beyond.
An adjustable flip chip allows you to raise or lower the bottom bracket by 6mm and increase or decrease the head angle, giving you the power to customize the setup to best suit how and where you ride. Rounding out the Escarpe 29 CR is a Shimano Deore 12-speed drivetrain and powerful Shimano MT420 or Sram DB8 4-piston hydraulic brakes.
It’s an uncompromising trail bike that’ll go up, down and everywhere in between.
THE ESCARPE 29 CR COMPONENT DETAILS
- Marzocchi Bomber Z2 fork & RockShox Deluxe Select R shock
- Shimano Deore M6100 12-speed drivetrain
- Shimano MT420 or Sram DB8 4-piston hydraulic disc brakes
- WTB ST Light i30 2.0 tubeless-ready wheelset with tubeless tape applied
- Maxxis Assegai & Dissector tires
| Material | CR – T700 carbon fiber front triangle, 6061-T6 aluminum rear / CRS, CRX & AMP – Full T800 carbon fiber front & rear triangles |
|---|---|
| Fork Travel | 150mm |
| Fork Offset | 44mm |
| Rear Travel | 140mm |
| Wheel Size | 29″ |
| Max Tire Size | 29″ x 2.5″ |
| Recommended Shock Sag (Measured seated) | 30% (18mm) |
| Shock Size | 205mm x 60mm |
| Shock Hardware (Top) | Trunnion |
| Shock Hardware (Bottom) | 30mm x 8mm |
| Sizing | S, M, L, XL |
| Head Tube | 44-56mm Tapered Semi-Integrated |
| Headset | ZS44/28.6 – ZS56/40 |
| Bearings Required | 4 x 6901-2RS, 8 x 6802V-2RS, 2 x 6902-2RS |
| Seatpost | 31.6mm |
| Seat Clamp | 36.4mm |
| BB | BSA Threaded, 73mm Shell |
| Rear Hub | 148mm x 12mm |
| Rear Axle | 180mm Length, 13mm Thread Length, M12xP1.0 Thread Pitch |
| Hanger | SRAM UDH |
| Chain Guide | ISCG 05 |
| Brake Mount | Post Mount, 180mm |
| Frame Protection | 3D Contoured Rubber Frame Protection for DT/SS/CS and protection film applied to high wear areas |
WHAT’S INCLUDED INSIDE THE BOX:
- The bicycle
- Pedals
- 10-piece multitool that includes:
- 2mm, 2.5mm, 3mm, 4mm, 5mm, 6mm, and 8mm Allen keys
- Phillips and flat head screwdrivers
- A T5 Torx
- 15mm pedal wrench
- Bottle of tire sealant
- Reflectors
- Bell
- Spoke protector disc
- User manual
- Any chargers or batteries used on the bike, such as batteries for electronic shifting or e-bike batteries
