Trek Supercaliber 9.8 Gx Mountain Bike
Nothing else like it
Supercaliber’s unique frame design ditches traditional suspension hardware so there’s less weight, less maintenance, and less lateral flex. IsoStrut connects the mainframe to the pivot-less seat stays to offer about 60mm of rear wheel travel. This design offers a unique blend of efficiency, traction, and fatigue-fighting compliance that keeps racers fresh and in control.
IsoStrut
IsoStrut integrated suspension gives you just enough travel to stay in control. It’s fully tuneable like a standard rear shock, but without the weight penalty of a full suspension bike.
OCLV Mountain Carbon
Trek’s mountain-specific carbon is engineered to withstand the extreme demands of off-road racing. Advanced analysis allows our designers to create a frame with the best blend of light weight, responsiveness, and just enough compliance in the seat stays to eliminate the need for a heavy rear pivot system.
Straight Shot w/Knock Block
Trek’s Straight Shot frame design optimizes the stiffness-to-weight ratio for a more responsive ride. You’ll be able to push harder and stay more planted on your line when the going gets rough.
| Frame | OCLV Mountain Carbon main frame & stays, IsoStrut, tapered head tube, Knock Block, Control Freak internal routing, Boost148, 60mm travel |
|---|---|
| Fork | Fox Performance 32 Step-Cast, Float EVOL air spring, GRIP 2-position damper, remote lockout, tapered steerer, 44mm offset, Boost110, 15mm Kabolt axle, 100mm travel |
| Shock | Trek IsoStrut, Fox Performance shock, air spring, DPS 2-position remote damper, 235mm x 32.5mm |
| Max compatible fork travel | 120mm (531mm axle-to-crown) |
| *Wheel front | Size: S, M, M/L, L, XL, XXL Bontrager Kovee Pro 30 Carbon, Tubeless Ready, 6-bolt, Boost110, 15mm thru axle |
|---|---|
| Size: S, M, M/L, L, XL, XXL Bontrager Kovee Pro 30 carbon, Tubeless Ready, 6-bolt, Boost110, 15mm thru axle |
|
| *Wheel rear | Size: S, M, M/L, L, XL, XXL Bontrager Kovee Pro 30, OCLV Mountain Carbon, Tubeless Ready, Rapid Drive 108, XD Driver, 6-bolt, Boost148, 12mm thru axle |
| Size: S, M, M/L, L, XL, XXL Bontrager Kovee Pro 30 carbon, Tubeless Ready, Rapid Drive 108, 6-bolt, SRAM XD driver, Boost148, 12mm thru axle |
|
| Skewer rear | Bontrager Switch thru axle, removable lever |
| Rim | Bontrager Kovee Pro 30, OCLV Mountain Carbon, Tubeless Ready |
| Tire | Bontrager XR2 Team Issue, Tubeless Ready, Inner Strength sidewall, aramid bead, 120 tpi, 29×2.20” |
| Tire part | Bontrager TLR sealant, 6oz |
| Rim strip | Bontrager TLR |
| Max tire size | Frame: 29×2.20″, Fork: See manufacturer |
| Shifter | SRAM GX Eagle, 12 speed |
|---|---|
| Rear derailleur | SRAM GX Eagle |
| *Crank | Size: S SRAM GX Eagle Carbon, DUB, 32T alloy ring, 52mm chainline, 170mm length |
| Size: M, M/L, L, XL, XXL SRAM GX Eagle Carbon, DUB, 32T alloy ring, 52mm chainline, 175mm length |
|
| Bottom bracket | SRAM DUB, 92mm, PressFit |
| Cassette | SRAM Eagle XG-1275, 10-52, 12 speed |
| Chain | SRAM GX Eagle, 12 speed |
| Max chainring size | 1x: 36T |
| Saddle | Bontrager Montrose Elite, titanium rails, 138mm width |
|---|---|
| *Seatpost | Size: S Bontrager Pro, OCLV Carbon, 31.6mm, 0mm offset, 330mm length |
| Size: M, M/L, L, XL, XXL Bontrager Pro, OCLV Carbon, 31.6mm, 0mm offset, 400mm length |
|
| Handlebar | Bontrager Kovee Pro, OCLV Carbon, 35mm, 5mm rise, 720mm width |
| Grips | ESI Chunky |
| *Stem | Size: S Bontrager Kovee Pro, 35mm, Knock Block, Blendr compatible, 13 degree, 60mm length |
| Size: M, M/L Bontrager Kovee Pro, 35mm, Knock Block, Blendr compatible, 13 degree, 70mm length |
|
| Size: L, XL Bontrager Kovee Pro, 35mm, Knock Block, Blendr compatible, 13 degree, 80mm length |
|
| Size: XXL Bontrager Kovee Pro, 35mm, Knock Block, Blendr compatible, 13 degree, 90mm length |
|
| Headset | Knock Block Integrated, 62-degree radius, cartridge bearing, 1-1/8” top, 1.5” bottom |
| Brake | Shimano Deore XT M8100 hydraulic disc |
| *Brake rotor | Size: S, M, M/L, L, XL, XXL Shimano RT76, 6-bolt, 160mm |
| Size: S, M, M/L, L, XL, XXL Shimano RT76, 6-bolt, 180mm |
|
| Rotor size | Max brake rotor sizes: 180mm front, 160mm rear |
| Weight | M – 10.38 kg / 22.88 lbs (with tubes) |
|---|---|
| Weight limit | This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 300 pounds (136 kg). |
| Size | Rider Height | Inseam |
|---|---|---|
| S |
155 – 165 cm 5’1″ – 5’5″ |
74 – 78 cm 29″ – 31″ |
| M |
165 – 176 cm 5’5″ – 5’9″ |
79 – 83 cm 31″ – 33″ |
| M/L |
173 – 180 cm 5’8″ – 5’11” |
81 – 86 cm 32″ – 34″ |
| L |
177 – 188 cm 5’10” – 6’2″ |
84 – 89 cm 33″ – 35″ |
| XL |
188 – 195 cm 6’2″ – 6’5″ |
89 – 91 cm 35″ – 36″ |
| 2XL |
195 – 203 cm 6’5″ – 6’8″ |
91 – 97 cm 36″ – 38″ |
