Trek Domane+ Lt Gen 1 Road Bike
Fast and efficient
Fazua’s lightweight drive system adds a punch of power when you need it, but rides and feels like a traditional bike when you don’t. You won’t feel much drag or resistance when you turn it off or pass the max level of assist. The system is also compatible with a smartphone app to let you check battery status and customize your ride.
Removable drivepack
When your ride doesn’t require an extra boost, replace the motor and battery with the storage cover (sold separately) to turn your bike into a regular Domane. You’ll also save 2.9kg in weight.
The smooth advantage
Front and Rear IsoSpeed soak up fatiguing bumps in the road so you can stay stronger longer.
| Frame | 500 Series OCLV Carbon, Fazua Evation integrated drive system, tapered head tube, rear IsoSpeed, internal routing, flat mount disc, fender mounts, 148x12mm thru axle |
|---|---|
| Fork | Domane SL carbon, tapered carbon steerer, internal brake routing, fender mounts, flat mount disc, 12x100mm thru axle |
| Frame fit | Endurance |
| Wheel front | DT Swiss G1800, tubeless compatible, 100x12mm thru axle |
|---|---|
| Wheel rear | DT Swiss G1800, tubeless compatible, 148x12mm thru axle |
| Skewer front | Bontrager Switch thru axle, removable lever |
| Skewer rear | Bontrager Switch thru axle, removable lever |
| Tire | Bontrager R3 Hard-Case Lite, Tubeless Ready, aramid bead, 120 tpi, 700x32c |
| Max tire size | 38c |
| Shifter | Shimano Ultegra R8020, 11 speed |
|---|---|
| Front derailleur | Shimano Ultegra R8000, braze-on |
| Rear derailleur | Shimano Ultegra R8000, long cage, 34T max cog |
| *Crank | Size: 50, 52 FSA Alloy for Fazua, 50/34 chainrings, 170mm length |
| Size: 54, 56 FSA Alloy for Fazua, 50/34 chainrings, 172.5mm length |
|
| Size: 58, 60, 62 FSA Alloy for Fazua, 50/34 chainrings, 175mm length |
|
| Cassette | Shimano Ultegra HG800, 11-34, 11 speed |
| Chain | Shimano Ultegra HG701, 11 speed |
| *Saddle | Size: 50, 52, 54, 56, 58, 60, 62 Bontrager Arvada Comp, steel rails, 138mm width |
|---|---|
| Size: 50, 52, 54, 56, 58, 60, 62 Bontrager Arvada Elite, stainless steel rails, 138mm width |
|
| *Seatpost | Size: 50, 52, 54, 56 Bontrager carbon internal seatmast cap, integrated light mount, 20mm offset, short length |
| Size: 58, 60, 62 Bontrager carbon internal seatmast cap, integrated light mount, 20mm offset, tall length |
|
| *Handlebar | Size: 50, 52 Bontrager Elite IsoZone VR-CF, alloy, 31.8mm, internal Di2 routing, 93mm reach, 123mm drop, 40cm width |
| Size: 54, 56 Bontrager Elite IsoZone VR-CF, alloy, 31.8mm, internal Di2 routing, 93mm reach, 123mm drop, 42cm width |
|
| Size: 58, 60, 62 Bontrager Elite IsoZone VR-CF, alloy, 31.8mm, internal Di2 routing, 93mm reach, 123mm drop, 44cm width |
|
| Handlebar tape | Bontrager Supertack Perf tape |
| *Stem | Size: 50 Bontrager Pro, 31.8mm, Blendr compatible, 7 degree, 80mm length |
| Size: 52, 54 Bontrager Pro, 31.8mm, Blendr compatible, 7 degree, 90mm length |
|
| Size: 56, 58 Bontrager Pro, 31.8mm, Blendr compatible, 7 degree, 100mm length |
|
| Size: 60, 62 Bontrager Pro, 31.8mm, Blendr compatible, 7 degree, 110mm length |
|
| Brake | Shimano Ultegra hydraulic disc, flat mount |
| *Brake rotor | Size: 50, 52, 54, 56, 58, 60, 62 Shimano MT800, centerlock, 160mm |
| Size: 50, 52, 54, 56, 58, 60, 62 Shimano EM810, centerlock 160mm |
| Battery | Fazua Evation battery, 250Wh |
|---|---|
| Charger | Fazua Evation charger, 90-120V |
| Motor | Fazua Evation Drive Pack, 20mph max assist |
| Computer | Fazua Evation touch remote |
| Weight | 32.3 lbs / 14.7 kg with drivepack, 26 lbs / 11.8 kg without drivepack (including storage cover, sold separately) |
|---|---|
| Weight limit | This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 275 pounds (125 kg). |
| Size | Rider Height | Inseam |
|---|---|---|
| 50 |
158 – 163 cm 5’2″ – 5’4″ |
74 – 77 cm 29″ – 30″ |
| 52 |
163 – 168 cm 5’4″ – 5’6″ |
76 – 79 cm 30″ – 31″ |
| 54 |
168 – 174 cm 5’6″ – 5’9″ |
78 – 82 cm 31″ – 32″ |
| 56 |
174 – 180 cm 5’9″ – 5’11” |
81 – 85 cm 32″ – 33″ |
| 58 |
180 – 185 cm 5’11” – 6’1″ |
84 – 87 cm 33″ – 34″ |
| 60 |
185 – 190 cm 6’1″ – 6’3″ |
86 – 90 cm 34″ – 35″ |
| 62 |
190 – 195 cm 6’3″ – 6’5″ |
89 – 92 cm 35″ – 36″ |
