• Frame

  • Canyon Neuron
  • Axle dimension: 12×148 mm
  • Material: Aluminium (AL)
• Rear Shock

  • Rock Shox Deluxe Select +
• Suspension Fork

  • Rock Shox Recon Silver RL
  • Axle dimension: 15×110 mm
  • Stanchion Diameter: 32 mm
  • Travel: 140 mm
  • Fork steer tube diameter: 1 1/8″ – 1,5″

• Rear Derailleur

  • Shimano Deore, 12-speed
  • 1×12 drivetrain for simpler, intuitive shifting. Long-cage design is compatible with wide-range cassettes.
• Shift Lever

  • Shimano Deore M6100 12s
  • Right shift lever. Shifts up to 3 gears at a time.
• Cassette

  • Shimano SLX, 12-speed (10-51)
  • Cassette size: 10-51T. Gear range: 510%.
• Crank

  • Miranda Delta
  • Number of chainrings: 1
• Bottom bracket

  • Race Face BSA Cinch
  • Race Face aluminium BSA bottom bracket with thicker walls for top durability. Housing dimensions: 68/73 mm.
  • Bottom bracket standard: BSA 68/73
• Chain

  • Shimano CN-M6100 12s

• Disc Brake

  • Shimano MT410
• Disc Brake

  • Shimano MT410
• Brake Rotor

  • Shimano RT10
  • Shimano’s 180mm RT10 rotor provides a good balance of stopping power and modulation.
  • Size: 180 mm

• Wheel

  • Iridium 30
  • Axle dimension: 15×110 mm
  • Rotor mount: Center Lock
  • Inner width: 30 mm
  • Wheelsize: 29″
• Wheel

  • Iridium 30
  • Axle dimension: 12×148 mm
  • Rotor mount: Center Lock
  • Inner width: 30 mm
  • Wheelsize: 29″
• Tyre

  • Schwalbe Nobby Nic 29×2.4″ black skin
  • Width: 2.4″
• Tyre

  • Schwalbe Wicked Will 29″x2.4″
  • Width: 2.4″
• Thru Axle

  • Canyon Quixle Thru Axle
  • The Canyon Quixle combines the stiffness of a through axle with the ease-of-use of a quick-release. You can quickly remove the rear wheel without tools. The handle discreetly slides into the axle after usage. The Quixle is only combined with the rear wheel.
  • Axle dimension: 12×148 mm

• Stem

  • Iridium Stem
  • Fork steer tube diameter: 1 1/8″
• Handlebar

  • Iridium Flatbar
  • Material: Aluminium
  • Rise: 5 mm
• Grips

  • Canyon Lock-On
  • Get the ideal mix of incredible direct feedback and comfort. The grips always stay firmly in place, thanks to the screw-tight clamp.

• Saddle

  • Selle Italia X3
  • Gender: Unisex
• Seatpost

  • Iridium Dropper
  • Clamp diameter: 30,9 mm
  • Material: Aluminium (AL)

• Pedals

  • None included
• Manuals and Accessories

  • Canyon Bag
  • Storage box for tools and replacement parts.
• Manuals and Accessories

  • Canyon Smallbox
  • Content: Manual, Torque Wrench incl. Bit Set, Shock Pump, Assembly Paste
• Manuals and Accessories

  • Quick Start Guide
