Vitus Sommet 297 Mountain Bike Frame
VITUS SOMMET 297 FRAME: STABLE, AGILE — BUILT FOR SPEED
Our big-hitting Vitus Sommet mountain bike just got bigger, bolder and more exciting. It’s the same old rush of the Sommet but with the fun dialed up so you can defy the rules and take your riding to a whole new level.
This frame-only version of the Sommet 297 comes with the Fox Float X2 Factory Series shock. With a supple 170mm of travel, the X2 Factory Series is a high-performance air shock that’s so popular it nearly needs no introduction. Designed to have a coil spring-like feel and an unmatched level of tunability, the X2 Factory Series is Kashima coated, has a two-position open/firm lever and loads of adjustability.
The Sommet is a bike that you sit within, not perched on top. It’s a primo platform for bike park laps, but the Sommet’s true home turf is in the maw of a janky backcountry descent. It stays planted on technical, unpredictable ground and thrives in the chaos of turbulent trails — a magic carpet floating on frenzy.
For gravity missions or between the tape at your local enduro, speed comes easily to the Sommet.
THE SOMMET 297 FRAME DETAILS
- Big hitting enduro bike with modern geometry
- Mixed-wheel platform balancing speed & agility
- Adjustable flip chip to fine tune handling and your preferred feel
- Ultra-smooth Fox Float X2 Factory Series shock
- Durable clear protection film applied to high wear areas
| Material | T700 carbon fiber front triangle, 6061-T6 aluminium rear |
|---|---|
| Fork Travel | 170mm |
| Fork Offset | 44mm |
| Rear Travel | 170mm |
| Wheel Size | 29″ Front / 27.5″ Rear |
| Max Tire Size | 27.5″ x 2.5″ |
| Recommended Shock Sag (Measured seated) | 30% (19mm) |
| Shock Size | 205mm x 65mm |
| Shock Hardware (Top) | Trunnion |
| Shock Hardware (Bottom) | 30mm x 8mm |
| Sizing | S, M, L, XL |
| Head Tube | 44-56mm Tapered Semi-Integrated |
| Headset | ZS44/28.6 – ZS56/40 |
| Bearings Required | 4 x 6901-2RS, 8 x 6802V-2RS, 2 x 6902-2RS |
| Seatpost | 31.6mm |
| Seat Clamp | 36.4mm |
| BB | BSA Threaded, 73mm Shell |
| Rear Hub | 148mm x 12mm |
| Rear Axle | 180mm Length, 13mm Thread Length, M12xP1.0 Thread Pitch |
| Hanger | SRAM UDH |
| Chain Guide | ISCG 05 |
| Brake Mount | Post Mount, 180mm |
| Frame Protection | 3D Contoured Rubber Frame Protection for DT/SS/CS and protection film applied to high wear areas |
WHAT’S INCLUDED INSIDE THE BOX:
- The Frame
- Headset
- Seat post collar
- Axle
- User manual
