Trek Top Fuel 9.9 Xx1 Axs Mountain Bike
Active Braking Pivot
Active Braking Pivot allows our engineers to tune how the suspension reacts to acceleration and braking forces independently. That means you get more confident control when you need it most.
Quick and in control
120mm of rear travel combined with progressive trail geometry gives you a fast, responsive ride that helps you keep your cool when the trail turns rowdy.
Internal Storage
Internal frame storage makes it easy to ditch the pack and still carry your ride essentials.
Hassle-free routing
Guided internal cable routing keeps Top Fuel quiet on the trail and maintenance a breeze.
Will my bike have a curved top tube?
Smaller frames (XS and S) have a curved top tube. This design makes for a lower standover height, which allows shorter riders to straddle the bike more easily. Larger frames (M and up) have a straight top tube because taller riders with longer legs typically don’t have the same issues with standover height.
| Frame | OCLV Mountain Carbon, internal storage, tapered head tube, Knock Block 2.0, internal guided routing, downtube guard, magnesium rocker link, Mino Link, ABP, Boost148, 120mm travel |
|---|---|
| Fork | RockShox SID Ultimate, DebonAir spring, Charger Race Day damper, tapered steerer, 44mm offset, Boost110, 15mm Maxle Stealth, 120mm travel |
| Shock | RockShox Deluxe Ultimate RCT, 185mm x 50mm |
| Max compatible fork travel | 130mm (541mm axle-to-crown) |
| Wheel front | Bontrager Line Pro 30, OCLV Mountain Carbon, Tubeless Ready, 6-bolt, Boost110, 15mm thru axle |
|---|---|
| Wheel rear | Bontrager Line Pro 30, OCLV Mountain Carbon, Tubeless Ready, Rapid Drive 108, 6-bolt, SRAM XD driver, Boost148, 12mm thru axle |
| Skewer rear | Bontrager Switch thru axle, removable lever |
| Tire | Bontrager XR4 Team Issue, Tubeless Ready, Inner Strength sidewalls, aramid bead, 120tpi, 29×2.40” |
| Tire part | Bontrager TLR sealant, 6oz |
| Max tire size | Frame: 29×2.50″, Fork: See manufacturer |
| Shifter | SRAM Eagle AXS, wireless, 12 speed |
|---|---|
| Rear derailleur | SRAM XX1 Eagle AXS |
| *Crank | Size: S, M, M/L, L SRAM XX1 Eagle, DUB, 30T alloy ring, 55mm chainline, 170mm length |
| Size: XL SRAM XX1 Eagle, DUB, 30T alloy ring, 55mm chainline, 175mm length | |
| Bottom bracket | SRAM DUB MTB Wide, 73mm, BSA threaded |
| Cassette | SRAM Eagle XG-1299, 10-52, 12 speed |
| Chain | SRAM XX1 Eagle, 12 speed |
| Max chainring size | 1x: 36T round, 34T oval, min 28T |
| Saddle | Bontrager Arvada, austenite rails, 138mm width |
|---|---|
| *Seatpost | Size: S RockShox Reverb AXS, 100mm travel, wireless, 34.9mm, 340mm length |
| Size: M, M/L RockShox Reverb AXS, 150mm travel, wireless, 34.9mm, 440mm length | |
| Size: L, XL RockShox Reverb AXS, 170mm travel, wireless, 34.9mm, 480mm length | |
| *Handlebar/stem (integrated) | Size: S Bontrager RSL Integrated handlebar/stem, OCLV Carbon, 27.5mm handlebar rise, 820mm width, 0 degree stem rise, 35mm stem length |
| Size: M, M/L, L, XL Bontrager RSL Integrated handlebar/stem, OCLV Carbon, 27.5mm handlebar rise, 820mm width, 0 degree stem rise, 45mm stem length | |
| Headset | Knock Block 2.0 Integrated, 72-degree radius (includes infinite-radius chip), sealed cartridge bearing, 1-1/8” top, 1.5” bottom |
| Brake | SRAM G2 Ultimate hydraulic disc, carbon levers |
| *Brake rotor | Size: S, M, M/L, L, XL SRAM CenterLine, 6-bolt, round-edge, 160mm |
| Size: S, M, M/L, L, XL SRAM CenterLine, 6-bolt, round edge, 180mm |
| Battery | SRAM eTap battery pack (with charger) |
|---|
| Weight | M – 11.90 kg / 26.24 lbs (with TLR sealant, no tubes) |
|---|---|
| Weight limit | This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 300 pounds (136 kg). |
| Size | Rider Height | Inseam |
|---|---|---|
| XS | 137 – 155 cm 4’6″ – 5’1″ | 64 – 73 cm 25″ – 29″ |
| S | 153 – 167 cm 5’0″ – 5’6″ | 72 – 79 cm 28″ – 31″ |
| M | 161 – 172 cm 5’3″ – 5’8″ | 76 – 81 cm 30″ – 32″ |
| M/L | 166 – 179 cm 5’5″ – 5’10” | 77 – 84 cm 30″ – 33″ |
| L | 177 – 188 cm 5’10” – 6’2″ | 83 – 88 cm 33″ – 35″ |
| XL | 186 – 196 cm 6’1″ – 6’5″ | 87 – 92 cm 34″ – 36″ |
