• Frame

  • Canyon Ultimate CF SLX Disc
  • 5th-generation Ultimate frame.
  • Classic road race design, engineered for the perfect balance of comfort, toughness, stiffness, lightness, and aerodynamics.
  • Axle dimension: 12×142 mm
  • Material: Carbon (CF)
• Fork

  • Canyon FK0104 CF Disc
  • Carbon fork optimised for lightness, stiffness, and strength.
  • Material: carbon
  • Steerer: 1 1/4″
  • Axle dimension: 12 x 100 mm
  • Brake mount: flat mount
  • Axle dimension: 12×100 mm
  • Material: Carbon (CF)

• Battery

  • SRAM eTap Powerpack
  • For charging SRAM eTap electronic shifting batteries
  • Contents: battery charger, USB cord
• Rear Derailleur

  • SRAM Force eTap AXS
  • With wireless shifting, orbit damper technology, and larger X-SYNC pulleys for improved durability
  • Max. cassette size: 33T
  • Weight: 325 g
• Front Derailleur

  • SRAM Force eTap AXS
  • With wireless shifting and AXS technology for easy customisation.
• Cassette

  • SRAM Force XG-1270, 12-speed, 10-28T
  • With mini cluster tech for reduced weight and increased durability.
  • Gear range: 10-28T
  • Number of sprockets: 12
• Crank

  • SRAM Force AXS Powermeter
  • Featuring Quarq’s premier integrated power measurement tech. One-piece chainring design significantly reduces weight.
  • Number of chainrings: 2
• Bottom bracket

  • SRAM Pressfit RED DUB
  • Pressfit BB86 road standard, compatible with SRAM DUB axles.
  • Bottom bracket standard: PF 86,5
• Chain

  • SRAM Force D1 12s
  • With signature flat-top design for quieter operation and increased strength and durability.

• Shift-/ Brake Lever

  • SRAM Force E-Tap, 12s
  • Right-hand shifter. 12 speed, wireless shifting, bite point and reach adjustment.
• Shift-/ Brake Lever

  • SRAM Force eTap AXS, 2-speed
  • Left-hand shifter. 12-speed, wireless shifting, bite point and reach adjustment.
• Brake Rotor

  • SRAM Paceline
  • Designed for optimal venting. With rounded edges for easier wheel installs.
  • Disc mount: centerlock
  • Weight: 155 g
• Brake Rotor

  • SRAM Paceline
  • Designed for optimal venting. With rounded edges for easier wheel installs.
  • Disc mount: centerlock
  • Weight: 155 g

• Wheel

  • DT Swiss ARC 1400 Dicut db
  • Front wheel with Aero+ technology for stability and low drag.
  • Tubeless-ready
  • Rim depth: 50 mm
  • Inner width: 20 mm
  • Weight: 716 g
• Wheel

  • DT Swiss ARC 1400 Dicut db XDR
  • Rear wheel with Aero+ technology for stability, low drag, speed, and pinpoint handling.
  • Tubeless-ready
  • Rim depth: 50 mm
  • Internal width: 20 mm
  • Hub: 240 Ratchet EXP
  • Weight: 836 g
• Tyre

  • Schwalbe Pro One, 25mm
  • High-end road tyre that combines suppleness, speed, and control at the highest level.
  • Tech: tubeless-ready, v-guard puncture protection
  • Compound: Addix Race
• Tyre

  • Schwalbe Pro One, 28mm
  • High-end road tyre that combines suppleness, speed, and control at the highest level.
  • Tech: tubeless-ready, v-guard puncture protection
  • Compound: Addix Race
• Thru Axle

  • DT Swiss through axle without lever
  • Aluminium construction.
  • Dimensions: 12×100 mm
  • Thread pitch: 1.75 mm
  • Axle dimension: 12×100 mm
• Thru Axle

  • DT Swiss through axle with lever
  • Aluminium construction.
  • Thread pitch: 1.75 mm
  • Axle dimension: 12×142 mm

• Cockpit

  • Canyon CP0018 Aerocockpit
  • Aero design, reinforced carbon walls for added stiffness and improved durability.
  • Easy width adjustment: +/-20 mm
  • Cut-free height adjustment: 15 mm
  • Weight: 440 g
  • Material: Carbon (CF)
• Handlebar Tape

  • Canyon Ergospeed Gel
  • Bar tape with EVA foam and elastomer gel mix for optimal comfort.
  • Color: black

• Saddle

  • Selle Italia SLR Boost Superflow Titanium
  • Saddle with modern short-nose design featuring unisex ergonomics.
  • Gender: Unisex
• Seatpost

  • Canyon SP0055
  • Custom carbon seatpost with aerodynamic D-shape profile.
  • Setback: 10 mm
  • Weight: 110 g

• Pedals

  • None included
• Manuals and Accessories

  • Canyon Bag
  • Storage box for tools and replacement parts.
• Manuals and Accessories

  • Canyon starter box
  • All you need to get riding: Quick Start Guide, manual, torque wrench incl. bit set, assembly paste.
• Manuals and Accessories

  • Quickstart Guide Ultimate CF
