Canyon Ultimate CF SL 7 eTap Road Bikes
Frame
- Frame
- Canyon Ultimate CF SL Disc
- Latest 5th-generation Ultimate frame.
- Classic road race design, engineered for the perfect balance of comfort, toughness, stiffness, lightness, and aerodynamics.
- Axle dimension: 12×142 mm
- Material: Carbon (CF)
- Fork
- Canyon FK0104 CF Disc
- Carbon fork optimised for lightness, stiffness, and strength.
- Material: carbon
- Steerer: 1 1/4”
- Axle dimension: 12 x 100 mm
- Brake mount: flat mount
- Axle dimension: 12×100 mm
- Material: Carbon (CF)
Drivetrain
- Battery
- SRAM eTap Powerpack
- For charging SRAM eTap electronic shifting batteries
- Contents: battery charger, USB cord
- Rear Derailleur
- SRAM Rival eTap AXS
- Rear derailleur with wireless shifting. Featuring robust steel bearings and spring clutch for quiet, secure operation.
- Cage material: aluminium
- Maximum cassette size: 36T.
- Front Derailleur
- SRAM Rival eTap AXS
- Front derailleur with wireless shifting. Featuring Yaw technology, eliminating the need for derailleur trim.
- Mounting type: braze-on
- Cassette
- SRAM Rival, 12-speed, 10-30T
- With SRAM’s premier X-Range gearing for a smoother progression over a greater gear range.
- Gear range: 10-30 T
- Crank
- SRAM Rival AXS Powermeter
- Two-by crankset with spindle-integrated Quarq power meter.
- Number of chainrings: 2
- Bottom bracket
- SRAM Pressfit RED DUB
- Pressfit BB86 road standard, compatible with SRAM DUB axles.
- Bottom bracket standard: PF 86,5
- Chain
- SRAM RIVAL D1 12s
- 12-speed chain with flattop technology for narrower design, quieter operation, and increased strength and durability.
Brakes
- Shift-/ Brake Lever
- SRAM Rival eTap AXS, 12-speed
- Right-hand shifter with hood shape optimised to fit hands of all sizes, for comfortable and controlled braking from any position. With wireless shifting, contact point adjustment, reach adjust.
- Shift-/ Brake Lever
- SRAM Rival eTap AXS, 2-speed
- Left-hand shifter with hood shape optimised to fit hands of all sizes, for comfortable and controlled braking from any position. With wireless shifting, contact point adjustment, reach adjust.
- Brake Rotor
- SRAM Paceline
- Designed for optimal venting. With rounded edges for easier wheel installs.
- Disc mount: centerlock
- Weight: 155 g
- Brake Rotor
- SRAM Paceline
- Designed for optimal venting. With rounded edges for easier wheel installs.
- Disc mount: centerlock
- Weight: 155 g
Wheels
- Wheel
- DT Swiss P 1800 Spline db
- Rim Material: Aluminium
- Rim Height: 23 mm
- Inner Width: 18 mm
- Weight: 763 g
- Wheel
- DT Swiss P 1800 Spline db
- Rotor mount: Center Lock
- Wheelsize: 28″
- Tyre
- Continental Grand Prix 5000, 28 mm, skinwall
- High-performance foldable clincher tyre made from high-grade BlackChili compound, with Vectran breaker for enhanced puncture protection. Tanwall sidewall.
- TPI: 330
- Weight: 240 g
- Thru Axle
- Canyon Thru Axle 12x100x1,75
- Axle dimension: 12×100 mm
- Thru Axle
- Canyon Thru Axle 12x142x1,75
- Axle dimension: 12×142 mm
Cockpit
- Cockpit
- Canyon CP0018 Aerocockpit
- Aero design, reinforced carbon walls for added stiffness and improved durability.
- Easy width adjustment: +/-20 mm
- Cut-free height adjustment: 15 mm
- Weight: 440 g
- Material: Carbon (CF)
- Handlebar Tape
- Canyon Ergospeed Gel
- Bar tape with EVA foam and elastomer gel mix for optimal comfort.
- Color: black
Seat
- Saddle
- Selle Italia SLR Boost Superflow S manganese
- Saddle with modern short-nose design and unisex ergonomics.
- Width: 130 mm (S)
- Rail material: manganese
- Weight: 208 g
- Seatpost
- Canyon SP0055
- Custom carbon seatpost with aerodynamic D-shape profile.
- Setback: 10 mm
- Weight: 110 g
Accessories
- Pedals
- None included
- Manuals and Accessories
- Canyon Bag
- Storage box for tools and replacement parts.
- Manuals and Accessories
- Canyon starter box
- All you need to get riding: Quick Start Guide, manual, torque wrench incl. bit set, assembly paste.
- Manuals and Accessories
- Quickstart Guide Ultimate CF
