Canyon Spectral 29 CFR Mountain Bike
Frame
- Frame
- Canyon Spectral CFR
- The Spectral CFR uses the most advanced carbon materials and layup to save 300 g over the CF models, with no loss of stiffness.
- Axle dimension: 12×148 mm
- Material: Carbon (CF)
- Rear Shock
- FOX Float X Factory EVOL
- Air-sprung shock from Fox’ premium Factory line. A 2-position (open/closed) platform lever lets you minimise the rear triangle’s movement, for efficient climbing.
- Dimensions: 230 x 60 mm.
- Suspension Fork
- FOX 36 Factory Grip2
- Axle dimension: 15×110 mm
- Stanchion Diameter: 36 mm
- Travel: 160 mm
- Fork steer tube diameter: 1 1/8″ – 1,5″
- Offset: 44 mm
Drivetrain
- Battery
- SRAM eTap Powerpack 1BY
- Removable battery for wireless eTap derailleurs.
- Charge time: less than 60 minutes.
- Rear Derailleur
- SRAM X01 Eagle AXS
- Precise 1×12 rear derailleur with wireless AXS technology.
- Chainguard
- Canyon GP0293-02
- Shift Lever
- SRAM Eagle AXS Controller
- Unsurpassed wireless 12 speed shifting. No need for cables, no need for fiddly cockpits, the AXS system frees up handlebar space and keeps gear changes neat and tidy.
- Cassette
- SRAM GX Eagle, 12-speed (10-52)
- Cassette size: 10-52T
- Gear range: 520%
- Crank
- SRAM X01 Eagle
- Number of chainrings: 1
- Bottom bracket
- SRAM BSA DUB
- Hassle-free SRAM DUB threaded bottom bracket.
- Bottom bracket standard: BSA 73
- Chain
- SRAM SX Eagle 12s
Brakes
- Disc Brake
- SRAM Code RSC
- Dependable front brake. With tool-free reach and bite point adjustment.
- Disc Brake
- SRAM Code RSC
- Brake Rotor
- SRAM HS2
- Size: 200 mm
Wheels
- Wheel
- DT Swiss XMC 1501
- Light, durable, high-end 29-inch carbon wheel.
- Tubeless-ready
- Internal rim width: 30 mm
- Axle dimensions: 15 x 110 mm
- Axle dimension: 15×110 mm
- Rotor mount: IS 6-bolt
- Rim height: 25 mm
- Inner width: 30 mm
- Wheelsize: 29″
- Wheel
- DT Swiss XMC1501 29″
- Light, durable, high-end 29-inch carbon wheel. Tubeless-ready. With reliable Ratchet EXP freewheel.
- Internal rim width: 30 mm
- Axle dimensions: boost,12 x 148 mm
- Tyre
- Maxxis Minion DHRII 3C MaxxTerra EXO 2,4×29“
- Wheelsize: 29″
- Tyre
- Maxxis Minion DHRII 3C MaxxTerra EXO+ 2,4×29
- Width: 2,4″
- Thru Axle
- Canyon Quixle Thru Axle
- The Canyon Quixle combines the stiffness of a through axle with the ease-of-use of a quick-release. You can quickly remove the rear wheel without tools. The handle discreetly slides into the axle after usage. The Quixle is only combined with the rear wheel.
- Axle dimension: 12×148 mm
Cockpit
- Stem
- Canyon G5 Stem
- Modern design, extreme durability: Canyon G5 components were developed by our pros on the world’s toughest trails.
- Fork steer tube diameter: 1 1/8″
- Clamping diameter: 31,8 mm
- Handlebar
- Canyon G5 Riser Bar
- G5 stands for gravity riding, and category 5. This aluminium bar has superb ergonomics and durability.
- Clamping diameter: 31,8 mm
- Width: 780 mm
- Rise: 30 mm
- Grips
- Canyon G5 Grips
- Get huge grip, with or without gloves. The clamp guarantees a tight lock on the bar.
Seat
- Saddle
- Ergon SM10 Enduro Comp
- Seatpost
- G5 Adjustable Dropper Post
- Clamp diameter: 30,9 mm
- Material: Aluminium (AL)
Accessories
- Pedals
- None included
- Manuals and Accessories
- Canyon Bag
- Storage box for tools and replacement parts.
- Manuals and Accessories
- Canyon Smallbox
- Content: Manual, Torque Wrench incl. Bit Set, Shock Pump, Assembly Paste
- Manuals and Accessories
- Canyon Quick Start Guide
