Canyon Spectral 29 CF 8 Mountain Bikes
Frame
- Frame
- Canyon Spectral CF 29
- Full-carbon frame with optimised stiffness-to-weight ratio. With Flip Chip system for simple geometry adjustment. Category 4.
- Axle dimension: 12×148 mm
- Material: Carbon (CF)
- Rear Shock
- FOX Float X Performance Elite
- Designed to meet the demands of aggressive trail riders, this shock combines advanced damping with light weight for outstanding performance and durability.
- Suspension Fork
- FOX 36 Performance Elite Grip2
- Axle dimension: 15×110 mm
- Stanchion Diameter: 36 mm
- Travel: 160 mm
- Fork steer tube diameter: 1 1/8″ – 1,5″
- Offset: 44 mm
Drivetrain
- Rear Derailleur
- Shimano Deore XT M8100 12speed
- Precise 1×12 drivetrain.
- Chainguard
- Canyon GP0293-02
- Shift Lever
- Shimano Deore XT, 12-speed
- Rear derailleur shifter, 12-speed, Textured rubber lever pad, Multi-Release, 2-way release, I-Spec EV clamp allows 14mm lateral adjustment and 20-degrees rotation adjustment, 130 g
- Cassette
- Shimano XT, 12-speed (10-51)
- Cassette size: 10-51T
- Gear range: 510%
- Crank
- Shimano XT M8120 32T
- Number of chainrings: 1
- Bottom bracket
- Shimano MT800, Threaded
- Hassle-free Shimano Hollowtech II threaded bottom bracket
- Bottom bracket standard: BSA 68/73
- Chain
- Shimano M6100 12-speed
- SIL-TEC treatment for extended offroad durability, HYPERGLIDE+ shift technology, quick link for easy connect and tool-free assembly
Brakes
- Disc Brake
- Shimano XT M8120
- High-power 4-piston brake, reach adjust, quick pad retraction, banjo-type connection, ICE TECH brake pads, 410 g
- Disc Brake
- Shimano Deore XT M8120
- High-power 4-piston brake, reach adjust, quick pad retraction, banjo-type connection, ICE TECH brake pads, 410 g
- Brake Rotor
- Shimano RT86, 203mm
- A big (203mm) Shimano RT86 brake rotor delivers equally big stopping power.
Wheels
- Wheel
- DT Swiss XM1700 29″
- DT Swiss’ XM1700 wheelset is plenty strong. Features include wide (30mm) aluminum rims and DT’s Ratchet-drive, Boost hubs.
- Rotor mount: IS 6-bolt
- Wheelsize: 29″
- Wheel
- DT Swiss XM1700 29″
- DT Swiss’ XM1700 wheelset is plenty strong. Features include wide (30mm) aluminum rims and DT’s Ratchet-drive, Boost hubs.
- Rotor mount: IS 6-bolt
- Wheelsize: 29″
- Tyre
- Maxxis Minion DHRII 3C MaxxTerra EXO 2,4×29“
- Wheelsize: 29″
- Tyre
- Maxxis Minion DHRII 3C MaxxTerra EXO+ 2,4×29
- Width: 2,4″
- Thru Axle
- Canyon Quixle Thru Axle
- The Canyon Quixle combines the stiffness of a through axle with the ease-of-use of a quick-release. You can quickly remove the rear wheel without tools. The handle discreetly slides into the axle after usage. The Quixle is only combined with the rear wheel.
- Axle dimension: 12×148 mm
Cockpit
- Stem
- Canyon G5 Stem
- Modern design, extreme durability: Canyon G5 components were developed by our pros on the world’s toughest trails.
- Fork steer tube diameter: 1 1/8″
- Clamping diameter: 31,8 mm
- Handlebar
- Canyon G5 Riser Bar
- G5 stands for gravity riding, and category 5. This aluminium bar has superb ergonomics and durability.
- Clamping diameter: 31,8 mm
- Width: 780 mm
- Rise: 30 mm
- Grips
- Canyon G5 Grips
- Get huge grip, with or without gloves. The clamp guarantees a tight lock on the bar.
Seat
- Saddle
- Ergon SM10 Enduro Comp
- Seatpost
- G5 Adjustable Dropper Post
- Clamp diameter: 30,9 mm
- Material: Aluminium (AL)
Accessories
- Pedals
- None included
- Manuals and Accessories
- Canyon Bag
- Storage box for tools and replacement parts.
- Manuals and Accessories
- Canyon Smallbox
- Content: Manual, Torque Wrench incl. Bit Set, Shock Pump, Assembly Paste
- Manuals and Accessories
- Canyon Quick Start Guide
