Canyon Spectral 125 CF 7 Mountain Bikes
Frame
- Frame
- Spectral CF 125
- Canyon Spectral 125 carbon frame. Frame model: M144. Excellent stiffness-to-weight ratio. Category 4.
- Material: Carbon (CF)
- Rear Shock
- RockShox Deluxe Select+
- Suspension Fork
- RockShox Pike Select+
- The individually adjustable DebonAir air spring is buttery-smooth, sensitive at the start of the stroke, and gives you more control when things get steep. Low-friction SKF seals ensure outstanding long-term performance.
- Axle dimension: 15×110 mm
- Stanchion Diameter: 35 mm
- Travel: 140 mm
- Fork steer tube diameter: 1 1/8″ – 1,5″
- Offset: 44 mm
Drivetrain
- Rear Derailleur
- SRAM GX Eagle, 12-speed
- Cage Lock and Roller Bearing Clutch technologies
- 12-speed
- Max cassette size: 52T
- Weight: 290 g
- Shift Lever
- SRAM GX Eagle
- SRAM’s GX Eagle 12-speed shifters fire off quick and accurate gear shifts.
- Cassette
- SRAM GX Eagle, 12-speed (10-52)
- Cassette size: 10-52T
- Gear range: 520%
- Crank
- SRAM X1 Eagle
- Number of chainrings: 1
- Bottom bracket
- SRAM BSA DUB
- Hassle-free SRAM DUB threaded bottom bracket.
- Bottom bracket standard: BSA 73
- Chain
- SRAM GX Eagle 12-speed
- Flowlink inner plate design reduces friction, solid pin construction, PowerLock tool-less master link.
Brakes
- Disc Brake
- SRAM Code RS
- Disc Brake
- SRAM Code RS
- Brake Rotor
- SRAM Centerline, 180mm
- Diameter: 180 mm.
- Brake Rotor
- SRAM Centerline, 200mm
- SRAM’s 200mm Centerline front rotor ensures you always have stopping power to spare.
Wheels
- Wheel
- DT Swiss M1900
- Rotor mount: IS 6-bolt
- Wheelsize: 29″
- Wheel
- DT Swiss M1900 XD
- Rotor mount: IS 6-bolt
- Wheelsize: 29″
- Tyre
- Maxxis Dissector 2.4″
- The Dissector rear tire offers outstanding traction and braking control.
- Width: 2.4″
- Tyre
- Maxxis Minion DHRII 3C MaxxTerra EXO 2,4×29“
- Wheelsize: 29″
- Thru Axle
- Canyon Quixle Thru Axle
- The Canyon Quixle combines the stiffness of a through axle with the ease-of-use of a quick-release. You can quickly remove the rear wheel without tools. The handle discreetly slides into the axle after usage. The Quixle is only combined with the rear wheel.
- Axle dimension: 12×148 mm
Cockpit
- Stem
- Canyon G5 Stem
- Modern design, extreme durability: Canyon G5 components were developed by our pros on the world’s toughest trails.
- Fork steer tube diameter: 1 1/8″
- Clamping diameter: 31,8 mm
- Handlebar
- Canyon G5 Riser Bar
- G5 stands for gravity riding, and category 5. This aluminium bar has superb ergonomics and durability.
- Clamping diameter: 31,8 mm
- Width: 780 mm
- Rise: 30 mm
- Grips
- Ergon GE1 Evo
Seat
- Saddle
- Ergon SM10 Enduro
- Developed on the Enduro World Series, the SM10 gives you max freedom of movement in technical terrain.
- Seatpost
- G5 Adjustable Dropper Post
- Clamp diameter: 30,9 mm
- Material: Aluminium (AL)
Accessories
- Pedals
- None included
- Manuals and Accessories
- Canyon Bag
- Storage box for tools and replacement parts.
- Manuals and Accessories
- Canyon Smallbox
- Content: Manual, Torque Wrench incl. Bit Set, Shock Pump, Assembly Paste
- Manuals and Accessories
- Canyon Quick Start Guide
