Canyon Lux Trail CF 7 Mountain Bikes
Frame
- Frame
- Lux Trail CF
- Lightweight, progressive, full-suspension carbon frame for greater control on rough tracks. Weight: 1,905 g. Rear travel: 110 mm. Wheel size: 29″.
- Rear Shock
- FOX Float DPS Performance Elite 3-Pos Remote
- With 3-position compression adjustment: open/trail/firm. With handlebar-mounted lockout. Dimensions: 210 x 55 mm.
- Tune: LCLLRL, CMF.
- Suspension Fork
- FOX 34 Stepcast Performance Elite 3-Pos Remote
- 120 mm travel. Stanchion diameter: 34 mm. 3-position compression adjustment: open/trail/firm. With handlebar-mounted lockout.
- 3 Volume spacer. 44mm Offset.
Drivetrain
- Rear Derailleur
- Shimano Deore XT M8100 12speed
- Precise 1×12 drivetrain.
- Shift Lever
- Shimano Deore XT, 12-speed
- Rear derailleur shifter, 12-speed, Textured rubber lever pad, Multi-Release, 2-way release, I-Spec EV clamp allows 14mm lateral adjustment and 20-degrees rotation adjustment, 130 g
- Cassette
- Shimano XT, 12-speed (10-51)
- Cassette size: 10-51T
- Gear range: 510%
- Crank
- Shimano Deore XT M8100 34T
- 34-tooth single chainring.
- Bottom bracket
- Shimano Pressfit BB71
- Bottom bracket bearings that are built to last, no matter what you throw at them.
- Bottom bracket standard: PF 89,5/92
- Chain
- Shimano M8100 12-speed
Brakes
- Disc Brake
- Shimano Deore XT M8100
- 2-piston brake callipers. With ergonomic design and adjustable levers.
- Disc Brake
- Shimano XT M8110
- 2-piston flat-mount brake callipers. With ergonomic design and adjustable levers.
- Brake Rotor
- Shimano RT-MT800, 180mm
- Size: 180 mm
- Brake Rotor
- Shimano RT-MT800, 160mm
- Size: 160 mm
Wheels
- Wheel
- DT Swiss XRC 1700 Spline
- Robust 29-inch carbon wheel. Internal rim width: 30 mm. Hub dimensions: 15 x 110 mm.
- Rotor Mount: CL. Hub Width, Axle Front: 110mm. Hub Width, Axle Rear: 148mm. Tubeless Technology: Taped.
- Wheel
- DT Swiss XRC 1700 Spline S12
- Robust 29-inch carbon wheel. Internal rim width: 30 mm. Hub: Ratchet SL, 12 x 148 mm.
- Rotor Mount: CL. Hub Width, Axle Front: 110mm. Hub Width, Axle Rear: 148mm. Tubeless Technology: Taped.
- Tyre
- Schwalbe Racing Ralph SR TLE EVO 2.35″
- Fast-rolling 29-inch cross-country tyre
- Width: 2.35″
- Tyre
- Schwalbe Wicked Will SR TLE EVO 2.4″
- 29-inch tyres combining the speed of a cross-country tyre with the grip of a trail tyre
- Width: 2.4″
- Thru Axle
- Canyon GP0415-04 Thru Axle 148X12
- The Canyon Quixle combines the ease-of-use of a quick release with the stiffness of a through axle. Dimensions: 148 x 12 mm.
Cockpit
- Stem
- Race Face Ride
- Durable, fuss-free alloy stem
- Length: 60 mm
- Material: 6061 aluminium
- Stem Spacer: S: 5, M: 10, L: 15, XL: 20
- Fork steer tube diameter: 1 1/8″
- Clamping diameter: 35,0 mm
- Handlebar
- Race Face Ride Riserbar
- Robust, reliable alloy bar
- Material: 6061 aluminium
- Upsweep: 5°
- Backsweep: 8°
- Clamping diameter: 35,0 mm
- Width: 760 mm
- Rise: 10 mm
- Grips
- Ergon GA20
- High-grade lock-on grips providing comfort and control in equal measure.
Seat
- Saddle
- Selle Italia SLS Boost FeC
- Saddle shaped to support a more aggressive riding position.
- Seatpost
- FOX Transfer SL Performance Elite
- Clamp diameter: 30,9 mm
- Material: Aluminium (AL)
Accessories
- Pedals
- None included
- Manuals and Accessories
- Canyon Bag
- Storage box for tools and replacement parts.
- Manuals and Accessories
- Canyon Smallbox
- Content: Manual, Torque Wrench incl. Bit Set, Shock Pump, Assembly Paste
