• Frame

  • Canyon Aeroad CFR Disc
  • Canyon Factory Racing R065 aero carbon frame, featuring ultra-rare Toray M40X carbon fibres. Shaped by extensive computational fluid dynamics analysis, validated in the wind tunnel. Fully internal routing, flat-mount disc standard. Weight: 915 g
  • Axle dimension: 12×142 mm
  • Material: Carbon (CFR)
• Fork

  • Canyon FK0060 CF Disc
  • Material: carbon
  • Steerer: 1 1/4”
  • Axle dimension: 12 x 100 mm
  • Brake mount: flat mount
  • Wheelsize: 700C
  • Fork steer tube diameter: 1 1/8″
  • Material: Carbon (CF)

• Battery

  • SRAM eTap Powerpack
  • For charging SRAM eTap electronic shifting batteries
  • Contents: battery charger, USB cord
• Rear Derailleur

  • SRAM Red eTap AXS, 12-speed
  • 12-speed, wireless shifting.
  • Max cassette size: 33T
  • Weight: 277 g
• Front Derailleur

  • SRAM RED eTap AXS
  • Wireless shifting for 2×12 drivetrains.
  • Braze-on mount
  • Weight: 105 g
• Cassette

  • SRAM RED XG-1290, 12-speed, 10-28
  • Machined one-piece design for smoother, faster shifting and weight savings. Gear range: 10-28T, weight: 175 g
  • Number of sprockets: 12
• Crank

  • SRAM Red AXS Powermeter
  • Featuring integrated dual-sided power meter, 2×12-speed, gearing: 48/35.
  • Bottom bracket: SRAM Pressfit RED DUB.
• Bottom bracket

  • SRAM Pressfit RED DUB
  • Pressfit BB86 road standard, compatible with SRAM DUB axles.
  • Bottom bracket standard: PF 86,5
• Chain

  • SRAM Red D1 12-speed
  • Premium 12-speed chain. Signature flat-top design enables a narrower design with quieter operation and increased strength and durability. With HollowPin construction and hard chrome plated inner link plates and rollers for reduced wear and prolonged life.

• Shift-/ Brake Lever

  • SRAM RED eTap AXS HRD, 12-speed
  • Left-hand shifter, 12-speed, wireless shifting. With bite point and reach adjustment. Weight: 143 g
• Shift-/ Brake Lever

  • SRAM RED eTap AXS HRD, 12-speed
  • Right-hand shifter, 12-speed, wireless shifting. With bite point and reach adjustment. Weight: 143 g
• Brake Rotor

  • SRAM Centerline X
  • Two-piece design centerlock brake rotor, rounded edges for easier wheel installs.
  • Weight: 135 g

• Wheel

  • ZIPP 454 NSW TL Hookless
  • Rotor mount: Center Lock
  • Rim height: 58 mm
  • Wheelsize: 28″
• Wheel

  • Zipp 454 NSW TL Hookless, XDR
  • Rotor mount: Center Lock
  • Rim height: 58 mm
  • Wheelsize: 28″
• Tyre

  • Continental GP 5000s TR, 28 mm
  • High-performance race tyre. Compound: BlackChili. Weight: 275 g, TPI: 3/330, with Vectran breaker for enhanced puncture protection
  • Width: 28mm
• Thru Axle

  • DT Swiss through axle without lever
  • Aluminium construction.
  • Dimensions: 12×100 mm
  • Thread pitch: 1.75 mm
  • Axle dimension: 12×100 mm
• Thru Axle

  • DT Swiss through axle with lever
  • Aluminium construction.
  • Thread pitch: 1.75 mm
  • Axle dimension: 12×142 mm

• Cockpit

  • Canyon CP0018 Aerocockpit
  • Aero design, reinforced carbon walls for added stiffness and improved durability.
  • Easy width adjustment: +/-20 mm
  • Cut-free height adjustment: 15 mm
  • Weight: 440 g
  • Material: Carbon (CF)
• Handlebar Tape

  • Canyon Ergospeed Gel
  • Bar tape with EVA foam and elastomer gel mix for optimal comfort.
  • Color: black

• Saddle

  • Fizik Vento Argo R3 Adaptive, 140mm
  • High-performance 3D printed saddle. With precise zonal cushioning for 60% reduction in peak pressure. High-grip surface. And superlight thanks to Fizik’s signature hollow Kium rails.
• Seatpost

  • Canyon SP0046 Aero Seatpost
  • Aero-optimised carbon seatpost with new sleeve bearing that creates a seal and reduces seatpost and seat tube friction and prevents dirt from entering.
  • Clamp diameter: 27,2 mm

• Pedals

  • None included
• Manuals and Accessories

  • Canyon Bag
  • Storage box for tools and replacement parts.
• Manuals and Accessories

  • Canyon starter box
  • All you need to get riding: Quick Start Guide, manual, torque wrench incl. bit set, assembly paste.
